Intro (00:01):
This is a Technikon podcast.
Peter Balint (host) (00:06):
Think for a moment -about the car of the future.
As you have probably guessed, it's quite smart. Meaning, your
car can make driving decisions for itself. It can react
to input with lightning speed and, all the while providing
new levels of safety and efficiency. So it stands to
(00:30):
reason that the car of the future must have a
really fast communication backbone. Right? I'm Peter Balint from Technikon,
welcome to today's episode. In previous podcasts, it's been said
that the car of the future resembles a data communications
center on wheels. The Car2TERA Project is helping to develop
(00:53):
this concept by exploring how to effectively use sub terahertz
frequencies to transfer critical data in the fastest, most reliable way.
In Car2TERA, the project partners are bringing their research to
life by constructing and demonstrating a prototype of an in-cabin
passenger monitoring system and a short range, high data rate
(01:15):
terahertz over plastic wired links. In Car2TERA, you would find
partners from Austria, Sweden, Poland, Italy and Spain. And today
we speak with Herbert Zirath, from Chalmers University of Technology
in Sweden. His team is focusing on designing and building
the circuits to be used in the demonstrators in Car2TERA .
(01:36):
Welcome Herbert, and thanks for coming on today.
Herbert Zirath (01:39):
Yeah, thank you for inviting me.
Peter Balint (host) (01:42):
Give us a quick overview of Car2TERA from your perspective.
Herbert Zirath (01:47):
Yes, the Car2TERA project is about applications in the terahertz
frequency range. So, in this project, we have chosen two
different demonstrators. One is a radar sensor for in-cabin monitoring
of people, for safety and security, and the other demonstrator
(02:12):
is a high data rate communication system for high data
rate communication over plastic fibre instead of copper cable, or
we communicate over optical fibre. But in this case, it's
terahertz waves that goes over plastic fibre... at very high
data rate. So these are two demonstrators we will build
(02:35):
at the end, OK?
Peter Balint (host) (02:37):
And the project deals with sub terahertz frequencies, which means
you need sort of a different approach and this is
perhaps where using optical fibre doesn't really perform well anymore.
You have to get something that can deal with the much,
much higher frequencies that are required in order to carry
out these superfast communications. Is that pretty much correct?
Herbert Zirath (03:01):
Yeah. Well, optical fibre are communicating at a much higher frequency.
So and it's not really a radio frequency technology anymore.
So we we are at frequencies above 100 gigahertz, say,
up to 3 or 400 gigahertz so that that's a frequency
(03:24):
range we want to cover.
Peter Balint (host) (03:25):
And then if we focus on your particular efforts, we'd
see that a part of this project, as you said,
is to build two demonstrators and your job along with
your team at Chalmers is to design the circuitry for this.
And can you tell us a little bit about what
you're doing there?
Herbert Zirath (03:43):
Yes, we designed various circuits for the demonstrators, such as amplifiers. So,
and that circuit is amplifying small signals so so they
can be demodulated. And so one can recover the data.
(04:05):
And there are also other functions we perform, like changing frequency...
so frequency translation. So we can, for instance, we can
change frequency from 150 gigahertz to 10 gigahertz... for instance,
the circuits, are called mixers. And then there are also on
(04:25):
the circuits we are exploring like frequency multipliers and frequency
multipliers simply multiply the frequency with the factor two, three
or four, etc. And then we put these circuits together
in a multifunction circuit to form a transmitter and a receiver,
(04:48):
which is the basis of actually both demonstrators. And so
both both in the radar sensor, we send out the
signal with which we we have formed in our circuits
and then we get the reflected way back from an
(05:10):
antenna and then we receive that signal and translate it to
a lower frequency, lower frequency where we can demodulate it.
It's similar with the high data rate communication over plastic
fibre so circuits can be reused actually.
Peter Balint (host) (05:35):
And for those people that maybe don't understand, for every
electronic component that comes to market, there has to be
quite a bit of research and design in the area
of the circuitry, and the circuitry is basically like a
roadmap for the electrons that are traveling to do their job.
So what you're doing, a lot of it is sort
(05:56):
of at the drawing board and then to practicality where
you build these demonstrators.
Herbert Zirath (06:03):
Exactly. In practical life, we simulate the performance in circuit
simulators to see that we get the type of specification
we want and then we make to what is called
art work, that this is the circuit layout, which is
the data the semiconductor factory needs for processing the circuits
(06:27):
and after it's processed ...in this case, it's Infineon who
make the processing of the circuits one of the partners
in in this project. We also measure the circuits, and
in case we are far off from the simulation, we
(06:47):
try to understand why. So it's quite a... one can
say repetitive work, we we have done a number of
these various processing rounds now.
Peter Balint (host) (07:04):
And of course, with these demonstrators, you have to build
them and then you have to test them. And when
we talked previously, you mentioned that the testing could sort
of be a challenge in this particular case and tell
us why that is.
Herbert Zirath (07:21):
It's yeah... due to different reasons. One reason is that
the equipment, the measurement equipment, they are not so well-developed
at these high frequencies. So we need to get around
that somehow. In some cases, we even have the problems
with equipment that break during the time. But it's not
(07:45):
only equipment problem, but it's also the problem to get
the signals in and out to the chip. I mean,
the chip is a small piece of silicon. It's the
number of square millimeter, say, three four square millimeter of
a silicon wafer. These signals have to get into the
(08:09):
chip and to get out to the chip at very
high frequencies. And this is also a challenge because typically
what you do with the electronic is that you package
a number of circuits on a circuit board. But this
is very complicated at at these high frequencies due to
(08:30):
parasitic components. So we have to get around that problem.
This can be done in various ways. One is to
develop the package and that is also what we do
in the project, but it takes a much longer time.
But it's possible also to use what is called coplanar waveguide probes .
(08:52):
So it's it's a probe that you contact the circuit
with and then then you can apply the signals and
you can take out the signals in the lab bench
environment and do the testing you want. So, so we
do both in this project. This probe testing is done
(09:16):
to get a fast result; if the circuits are working or not,
but then in the demonstrators, we need to have the
circuit packaged so that that's one of the activities in
the project. Also to to put put the circuit in
the package so we can put it on a circuit board.
Peter Balint (host) (09:36):
And it sounds like maybe a lot of these challenges
that you experience are because you're just working in these
super high frequencies that haven't really been rolled out on
a large scale. It's still sort of new.
Herbert Zirath (09:48):
Yeah, that's true. I mean, from basic research several groups
are working in this frequency range. But now we're talking
about making demonstrators that can be scaled up in high
production and even make it to a consumer product. That's
a different... totally different story then it cannot be expensive packaging,
(10:13):
for instance, so we need to find a low cost
package for this. That's also an activity in the project
and Infineon is developing these types of packages. We work together
with them. So it covers really a lot of activities.
(10:33):
This project, it's not only about the design of the circuits,
it's much more than that.
Peter Balint (host) (10:40):
Sure. And so with the work that you're doing on Car2TERA,
I wonder what kind of effect did the pandemic have
on your team?
Herbert Zirath (10:48):
Yeah, of course it has affected us somewhat. We have
had all meetings as video conferences, and I think many
people have learned how to use these various programs now.
So I think that this has worked very well. But
(11:11):
then we are somewhat restricted to be on campus also.
So the access to to the labs, for instance, has
been somewhat restricted. So it has had some limitations. But
I think we are pretty much on on the target.
I mean, where we are delayed a bit, but I
(11:33):
think we can manage that.
Peter Balint (host) (11:35):
Do you think when the COVID pandemic is gone do
you think we could sort of cope with less travel
than we have in the past?
Herbert Zirath (11:44):
Yes, absolutely. I think many people will save a lot
of time because travelling usually takes two days. Of course,
you would need to have some meetings face to face,
but I think a lot of meetings will be over
video conference and the tools are getting better and better. So.
(12:08):
So I think we will see more more of this
in the future.
Peter Balint (host) (12:13):
Yeah, this is a good point and kind of a
tragic way to learn how we could be more efficient.
But in the end, I'm hearing this from a lot
of different individuals that, you know, we're uncovering new ways
to work, and this is probably a good thing.
Herbert Zirath (12:27):
Yes. I think another thing is that, uh, people will
work more from home also to a larger extent, maybe
a few days per week, if that's possible. I mean,
everyone cannot do it, but the people normally working at
the offices can possibly do that. And I think also
(12:52):
companies will save office space due to this.
Peter Balint (host) (12:58):
For sure yeah, without a doubt. I'm curious also from your side,
what other challenges did you encounter what unexpected roadblocks that
you run into?
Herbert Zirath (13:09):
Not that many, really, I mean, COVID, we have covered,
and I think I mentioned also that we had some
instrument that broke. So, but apart from that, I think
it has worked pretty smooth and we have regular contact
with the partners, both all together, but also between individual
(13:32):
partners to resolve problems we see on the way. So
I think it has been rather smooth during the project.
Peter Balint (host) (13:40):
OK, now I want to turn to a news item
and this kind of made me think of the Car2TERA
project in a way; we're hearing about companies like Volvo,
for example, who recently announced that they will halt their
production line. And it's not because of waning customer demand,
but because of chip shortages. And there should be an
(14:00):
effort to make the EU more independent when it comes
to supplying microchips. And I'm wondering what kind of inroads
is Car2TERA making in this effort?
Herbert Zirath (14:14):
Car2TERA is really based on semiconductor technology, both on the antenna
side and the part where KTH is doing their effort
in micro machining and micro electromechanical systems. So one can
say that that's a part of semiconductor industry as well or research
(14:39):
and then definitely Infineon processes are really in the leading
edge in its area. That is for very high frequencies
so that there are many other semiconductor companies in Europe
as well, like SD Microelectronics, Infineon and XP to mention
(15:03):
a few. I think it has become apparent now that
that we have to use European suppliers more more than before.
I think some of the processes are very difficult to
build up in Europe, like the few nanometer CMOS processes
(15:26):
and because those factories are extremely challenging and extremely expensive
as well. Of course, now now it's a shortage, but
we don't know. After two years, if if there would
be a shortage anymore and if Europe then pay for
(15:48):
these very expensive factories, there would be overproduction maybe. So
that I think that that that could be a problem, really.
If we believe in Europe, that we very easily can
can build the same factory as TSMC, for instance, or Intel.
I mean, they have developed the technology for many, many years,
(16:11):
and it's not so easy to to copy it. But
we have other processes which are very important, like the
high frequency silicon germanium and CMOS. We have also CMOS
in Europe and we have power electronics so that there
are some semiconductor areas where we are very competitive and
(16:35):
I think it's very important to to keep that. And
then I think I haven't really seen any real data
on on exactly what circuits are in shortage. But I
think it's it's about graphical processors which is used for
(16:56):
the cryptomarket... cryptomining. So, it's it's a little bit uncertain, really,
for me, at least, the specific circuits which are lacking.
Nobody says really what it is.
Peter Balint (host) (17:13):
OK, it's interesting.
Herbert Zirath (17:14):
Yeah, I think so. I think journalists should do better
work there and try to find out, OK, what really
what circuits are we're talking about? We can just guess I
think it's GPUs and DRAMS but maybe micro processors or microcontrollers.
Peter Balint (host) (17:37):
Mm-Hmm. Yeah, it sounds like this maybe is not such
a easy problem to solve, but something that will require
a lot of attention over the next few years to
see which way things go.
Herbert Zirath (17:46):
Absolutely. It's very critical for the car industry now, for instance.
Peter Balint (host) (17:53):
Now, if you look forward a little bit, can you
predict or say which new technologies could come out of
this car to terror project?
Herbert Zirath (18:01):
Yeah. I mean, the baseline is the SiGe semiconductor process, and we
are designing in the new process called B12, which is
a top notch silicon germanium process that can cover frequencies
up to maybe 500 gigahertz or so, that will definitely
(18:25):
if we can make demonstrators, that could be a consumer product.
This would be very good for those processes then what
KTH is doing. That's the micro machine silicon and micro
electro mechanical systems, which is also based on silicon. That
(18:46):
could also be scaled up in production, and one can
integrate that in fabrication process in the future. We'd say
silicon germanium semiconductor process. So this is also something one
can look at in the future -how to integrate the
active electronics with with the passive ones. And that's really
(19:10):
something which is new today for these applications. Besides, we
were also working with graphene electronics, which is even more challenging.
What we try to do there is to make frequency converters.
And if that's working, this could also be a technology
(19:35):
that might come to mass production. But there are many
challenges left in in this area.
Peter Balint (host) (19:43):
This sounds great. The hope really of any H2020 project
is to develop future technologies. And to me, it sounds
like in Car2TERA there are many promising opportunities. Thanks for
the updates on the project, and your work is definitely
augmenting Europe's existing success story on advanced smart electronic sensor systems.
(20:05):
So thanks.
Herbert Zirath (20:06):
Yes, it has been a pleasure to be here.
Outro (20:13):
For more information about the Car2TERA Project, go to car2tera.eu.
The Car2TERA project has received funding from the European Union's
Horizon 2020 Research and Innovation Programme under grant agreement Number
824962
This is a Technikon podcast.
Peter Balint (host) (00:06):
Think for a moment -about the car of the future.
As you have probably guessed, it's quite smart. Meaning, your
car can make driving decisions for itself. It can react
to input with lightning speed and, all the while providing
new levels of safety and efficiency. So it stands to
(00:30):
reason that the car of the future must have a
really fast communication backbone. Right? I'm Peter Balint from Technikon,
welcome to today's episode. In previous podcasts, it's been said
that the car of the future resembles a data communications
center on wheels. The Car2TERA Project is helping to develop
(00:53):
this concept by exploring how to effectively use sub terahertz
frequencies to transfer critical data in the fastest, most reliable way.
In Car2TERA, the project partners are bringing their research to
life by constructing and demonstrating a prototype of an in-cabin
passenger monitoring system and a short range, high data rate
(01:15):
terahertz over plastic wired links. In Car2TERA, you would find
partners from Austria, Sweden, Poland, Italy and Spain. And today
we speak with Herbert Zirath, from Chalmers University of Technology
in Sweden. His team is focusing on designing and building
the circuits to be used in the demonstrators in Car2TERA .
(01:36):
Welcome Herbert, and thanks for coming on today.
Herbert Zirath (01:39):
Yeah, thank you for inviting me.
Peter Balint (host) (01:42):
Give us a quick overview of Car2TERA from your perspective.
Herbert Zirath (01:47):
Yes, the Car2TERA project is about applications in the terahertz
frequency range. So, in this project, we have chosen two
different demonstrators. One is a radar sensor for in-cabin monitoring
of people, for safety and security, and the other demonstrator
(02:12):
is a high data rate communication system for high data
rate communication over plastic fibre instead of copper cable, or
we communicate over optical fibre. But in this case, it's
terahertz waves that goes over plastic fibre... at very high
data rate. So these are two demonstrators we will build
(02:35):
at the end, OK?
Peter Balint (host) (02:37):
And the project deals with sub terahertz frequencies, which means
you need sort of a different approach and this is
perhaps where using optical fibre doesn't really perform well anymore.
You have to get something that can deal with the much,
much higher frequencies that are required in order to carry
out these superfast communications. Is that pretty much correct?
Herbert Zirath (03:01):
Yeah. Well, optical fibre are communicating at a much higher frequency.
So and it's not really a radio frequency technology anymore.
So we we are at frequencies above 100 gigahertz, say,
up to 3 or 400 gigahertz so that that's a frequency
(03:24):
range we want to cover.
Peter Balint (host) (03:25):
And then if we focus on your particular efforts, we'd
see that a part of this project, as you said,
is to build two demonstrators and your job along with
your team at Chalmers is to design the circuitry for this.
And can you tell us a little bit about what
you're doing there?
Herbert Zirath (03:43):
Yes, we designed various circuits for the demonstrators, such as amplifiers. So,
and that circuit is amplifying small signals so so they
can be demodulated. And so one can recover the data.
(04:05):
And there are also other functions we perform, like changing frequency...
so frequency translation. So we can, for instance, we can
change frequency from 150 gigahertz to 10 gigahertz... for instance,
the circuits, are called mixers. And then there are also on
(04:25):
the circuits we are exploring like frequency multipliers and frequency
multipliers simply multiply the frequency with the factor two, three
or four, etc. And then we put these circuits together
in a multifunction circuit to form a transmitter and a receiver,
(04:48):
which is the basis of actually both demonstrators. And so
both both in the radar sensor, we send out the
signal with which we we have formed in our circuits
and then we get the reflected way back from an
(05:10):
antenna and then we receive that signal and translate it to
a lower frequency, lower frequency where we can demodulate it.
It's similar with the high data rate communication over plastic
fibre so circuits can be reused actually.
Peter Balint (host) (05:35):
And for those people that maybe don't understand, for every
electronic component that comes to market, there has to be
quite a bit of research and design in the area
of the circuitry, and the circuitry is basically like a
roadmap for the electrons that are traveling to do their job.
So what you're doing, a lot of it is sort
(05:56):
of at the drawing board and then to practicality where
you build these demonstrators.
Herbert Zirath (06:03):
Exactly. In practical life, we simulate the performance in circuit
simulators to see that we get the type of specification
we want and then we make to what is called
art work, that this is the circuit layout, which is
the data the semiconductor factory needs for processing the circuits
(06:27):
and after it's processed ...in this case, it's Infineon who
make the processing of the circuits one of the partners
in in this project. We also measure the circuits, and
in case we are far off from the simulation, we
(06:47):
try to understand why. So it's quite a... one can
say repetitive work, we we have done a number of
these various processing rounds now.
Peter Balint (host) (07:04):
And of course, with these demonstrators, you have to build
them and then you have to test them. And when
we talked previously, you mentioned that the testing could sort
of be a challenge in this particular case and tell
us why that is.
Herbert Zirath (07:21):
It's yeah... due to different reasons. One reason is that
the equipment, the measurement equipment, they are not so well-developed
at these high frequencies. So we need to get around
that somehow. In some cases, we even have the problems
with equipment that break during the time. But it's not
(07:45):
only equipment problem, but it's also the problem to get
the signals in and out to the chip. I mean,
the chip is a small piece of silicon. It's the
number of square millimeter, say, three four square millimeter of
a silicon wafer. These signals have to get into the
(08:09):
chip and to get out to the chip at very
high frequencies. And this is also a challenge because typically
what you do with the electronic is that you package
a number of circuits on a circuit board. But this
is very complicated at at these high frequencies due to
(08:30):
parasitic components. So we have to get around that problem.
This can be done in various ways. One is to
develop the package and that is also what we do
in the project, but it takes a much longer time.
But it's possible also to use what is called coplanar waveguide probes .
(08:52):
So it's it's a probe that you contact the circuit
with and then then you can apply the signals and
you can take out the signals in the lab bench
environment and do the testing you want. So, so we
do both in this project. This probe testing is done
(09:16):
to get a fast result; if the circuits are working or not,
but then in the demonstrators, we need to have the
circuit packaged so that that's one of the activities in
the project. Also to to put put the circuit in
the package so we can put it on a circuit board.
Peter Balint (host) (09:36):
And it sounds like maybe a lot of these challenges
that you experience are because you're just working in these
super high frequencies that haven't really been rolled out on
a large scale. It's still sort of new.
Herbert Zirath (09:48):
Yeah, that's true. I mean, from basic research several groups
are working in this frequency range. But now we're talking
about making demonstrators that can be scaled up in high
production and even make it to a consumer product. That's
a different... totally different story then it cannot be expensive packaging,
(10:13):
for instance, so we need to find a low cost
package for this. That's also an activity in the project
and Infineon is developing these types of packages. We work together
with them. So it covers really a lot of activities.
(10:33):
This project, it's not only about the design of the circuits,
it's much more than that.
Peter Balint (host) (10:40):
Sure. And so with the work that you're doing on Car2TERA,
I wonder what kind of effect did the pandemic have
on your team?
Herbert Zirath (10:48):
Yeah, of course it has affected us somewhat. We have
had all meetings as video conferences, and I think many
people have learned how to use these various programs now.
So I think that this has worked very well. But
(11:11):
then we are somewhat restricted to be on campus also.
So the access to to the labs, for instance, has
been somewhat restricted. So it has had some limitations. But
I think we are pretty much on on the target.
I mean, where we are delayed a bit, but I
(11:33):
think we can manage that.
Peter Balint (host) (11:35):
Do you think when the COVID pandemic is gone do
you think we could sort of cope with less travel
than we have in the past?
Herbert Zirath (11:44):
Yes, absolutely. I think many people will save a lot
of time because travelling usually takes two days. Of course,
you would need to have some meetings face to face,
but I think a lot of meetings will be over
video conference and the tools are getting better and better. So.
(12:08):
So I think we will see more more of this
in the future.
Peter Balint (host) (12:13):
Yeah, this is a good point and kind of a
tragic way to learn how we could be more efficient.
But in the end, I'm hearing this from a lot
of different individuals that, you know, we're uncovering new ways
to work, and this is probably a good thing.
Herbert Zirath (12:27):
Yes. I think another thing is that, uh, people will
work more from home also to a larger extent, maybe
a few days per week, if that's possible. I mean,
everyone cannot do it, but the people normally working at
the offices can possibly do that. And I think also
(12:52):
companies will save office space due to this.
Peter Balint (host) (12:58):
For sure yeah, without a doubt. I'm curious also from your side,
what other challenges did you encounter what unexpected roadblocks that
you run into?
Herbert Zirath (13:09):
Not that many, really, I mean, COVID, we have covered,
and I think I mentioned also that we had some
instrument that broke. So, but apart from that, I think
it has worked pretty smooth and we have regular contact
with the partners, both all together, but also between individual
(13:32):
partners to resolve problems we see on the way. So
I think it has been rather smooth during the project.
Peter Balint (host) (13:40):
OK, now I want to turn to a news item
and this kind of made me think of the Car2TERA
project in a way; we're hearing about companies like Volvo,
for example, who recently announced that they will halt their
production line. And it's not because of waning customer demand,
but because of chip shortages. And there should be an
(14:00):
effort to make the EU more independent when it comes
to supplying microchips. And I'm wondering what kind of inroads
is Car2TERA making in this effort?
Herbert Zirath (14:14):
Car2TERA is really based on semiconductor technology, both on the antenna
side and the part where KTH is doing their effort
in micro machining and micro electromechanical systems. So one can
say that that's a part of semiconductor industry as well or research
(14:39):
and then definitely Infineon processes are really in the leading
edge in its area. That is for very high frequencies
so that there are many other semiconductor companies in Europe
as well, like SD Microelectronics, Infineon and XP to mention
(15:03):
a few. I think it has become apparent now that
that we have to use European suppliers more more than before.
I think some of the processes are very difficult to
build up in Europe, like the few nanometer CMOS processes
(15:26):
and because those factories are extremely challenging and extremely expensive
as well. Of course, now now it's a shortage, but
we don't know. After two years, if if there would
be a shortage anymore and if Europe then pay for
(15:48):
these very expensive factories, there would be overproduction maybe. So
that I think that that that could be a problem, really.
If we believe in Europe, that we very easily can
can build the same factory as TSMC, for instance, or Intel.
I mean, they have developed the technology for many, many years,
(16:11):
and it's not so easy to to copy it. But
we have other processes which are very important, like the
high frequency silicon germanium and CMOS. We have also CMOS
in Europe and we have power electronics so that there
are some semiconductor areas where we are very competitive and
(16:35):
I think it's very important to to keep that. And
then I think I haven't really seen any real data
on on exactly what circuits are in shortage. But I
think it's it's about graphical processors which is used for
(16:56):
the cryptomarket... cryptomining. So, it's it's a little bit uncertain, really,
for me, at least, the specific circuits which are lacking.
Nobody says really what it is.
Peter Balint (host) (17:13):
OK, it's interesting.
Herbert Zirath (17:14):
Yeah, I think so. I think journalists should do better
work there and try to find out, OK, what really
what circuits are we're talking about? We can just guess I
think it's GPUs and DRAMS but maybe micro processors or microcontrollers.
Peter Balint (host) (17:37):
Mm-Hmm. Yeah, it sounds like this maybe is not such
a easy problem to solve, but something that will require
a lot of attention over the next few years to
see which way things go.
Herbert Zirath (17:46):
Absolutely. It's very critical for the car industry now, for instance.
Peter Balint (host) (17:53):
Now, if you look forward a little bit, can you
predict or say which new technologies could come out of
this car to terror project?
Herbert Zirath (18:01):
Yeah. I mean, the baseline is the SiGe semiconductor process, and we
are designing in the new process called B12, which is
a top notch silicon germanium process that can cover frequencies
up to maybe 500 gigahertz or so, that will definitely
(18:25):
if we can make demonstrators, that could be a consumer product.
This would be very good for those processes then what
KTH is doing. That's the micro machine silicon and micro
electro mechanical systems, which is also based on silicon. That
(18:46):
could also be scaled up in production, and one can
integrate that in fabrication process in the future. We'd say
silicon germanium semiconductor process. So this is also something one
can look at in the future -how to integrate the
active electronics with with the passive ones. And that's really
(19:10):
something which is new today for these applications. Besides, we
were also working with graphene electronics, which is even more challenging.
What we try to do there is to make frequency converters.
And if that's working, this could also be a technology
(19:35):
that might come to mass production. But there are many
challenges left in in this area.
Peter Balint (host) (19:43):
This sounds great. The hope really of any H2020 project
is to develop future technologies. And to me, it sounds
like in Car2TERA there are many promising opportunities. Thanks for
the updates on the project, and your work is definitely
augmenting Europe's existing success story on advanced smart electronic sensor systems.
(20:05):
So thanks.
Herbert Zirath (20:06):
Yes, it has been a pleasure to be here.
Outro (20:13):
For more information about the Car2TERA Project, go to car2tera.eu.
The Car2TERA project has received funding from the European Union's
Horizon 2020 Research and Innovation Programme under grant agreement Number
824962
Popular Podcasts
On Purpose with Jay Shetty
I’m Jay Shetty host of On Purpose the worlds #1 Mental Health podcast and I’m so grateful you found us. I started this podcast 5 years ago to invite you into conversations and workshops that are designed to help make you happier, healthier and more healed. I believe that when you (yes you) feel seen, heard and understood you’re able to deal with relationship struggles, work challenges and life’s ups and downs with more ease and grace. I interview experts, celebrities, thought leaders and athletes so that we can grow our mindset, build better habits and uncover a side of them we’ve never seen before. New episodes every Monday and Friday. Your support means the world to me and I don’t take it for granted — click the follow button and leave a review to help us spread the love with On Purpose. I can’t wait for you to listen to your first or 500th episode!
Crime Junkie
Does hearing about a true crime case always leave you scouring the internet for the truth behind the story? Dive into your next mystery with Crime Junkie. Every Monday, join your host Ashley Flowers as she unravels all the details of infamous and underreported true crime cases with her best friend Brit Prawat. From cold cases to missing persons and heroes in our community who seek justice, Crime Junkie is your destination for theories and stories you won’t hear anywhere else. Whether you're a seasoned true crime enthusiast or new to the genre, you'll find yourself on the edge of your seat awaiting a new episode every Monday. If you can never get enough true crime... Congratulations, you’ve found your people. Follow to join a community of Crime Junkies! Crime Junkie is presented by audiochuck Media Company.
Ridiculous History
History is beautiful, brutal and, often, ridiculous. Join Ben Bowlin and Noel Brown as they dive into some of the weirdest stories from across the span of human civilization in Ridiculous History, a podcast by iHeartRadio.
